ZZ1316N266GF1
Allison 4430P Transmission
Euro 6 Emission Compliant
7.6m3 capacity
Pressurised Water System
Factory Made Bowl with Wireless Remote
Extendable Chute, Bucket and Scraper Holder
Extendable chute, bucket and scraper holder.
Factory Made Bowl with Wireless Remote.
GVM: 27,500kg
Max load of two axles: (Front) 5500/5500kg
Max load of two axles: (Rear) 16,500kg
Max speed: 100km/h
Min turning diameter: 22.5m
Max climb gradient: 25%
Fuel Tank Capacity: 220L
Model: G5S-M
Seats: 2
Cab turning radius: 2410mm
Model: MC07H.35-61
Displacement: 7.36L
Power Rating: 340HP
Max Torque: 1400 / (1200~1600)
Model: Allison 4430P
Model: Trapezium frame
Main beam cross-section: 280mm × 80mm × 6mm
Width of frame assembly: (Front) 940mm
Width of frame assembly: (Rear) 850mm
Model: MCY11BES
Redactor ratio: 5.29
Differential Lock: Diff lock
Model: VPD71DS
Model: Ball circle
Ratio: 22.2~26.2:1
Max pressure of pump: 20,000kPa
Working pressure: 1250kPa
Drive braking type: Dual circuit compressed air brake
Brake power adjust type: EBS + ESC + HSA
Parking brake type: Spring stored energy air cut brake
Circuit type: Dual
Voltage: 24V
Generator power: 3.08kW
Batteries: 2 x 12 / 180Ah
Tank length: 4600mm
Maximum diameter of tank: 2135mm
Geometric volume: 12.4m3
Stirring volume: 7.6m3
Loading factor: 61.2%
Tilt angle: 140
Rotation speed: 0-16r/min
Tank material: 3mm Hardox
Blade material: 5mm 520JJ
Residual rate: ≤0.2%
Feeding speed: ≥3m3/min
Discharge speed: ≥2m3/min
Reducer: PMB 6 R100
Oil pump: A10VGT090EP4P0/11NRNC-4C92G0000AS0-Y
Motor: A2FMT090/70NWVC4V802G00-Y
Heat sink: KT-YS-26L-JB006(HJ)QDZQ
Water tank volume: 200L
Water supply method: Water tank air pressure
